LDMOS 6/4m 50-72MHz LINEAR AMPLIFIER 1200W

USE FOR LDMOS BLF188XR / MRF1K50 / MRFX1K80 / ART2K0FE

RF INPUT: 0-8W MAX
RF OUTPUT: 0-1250W MAX

POWER SUPPLY: 48-54V 35A
CLASS AB PUSH PULL

A high power low loss wide band transmission line type TLT transformer are used in amplifier.
Temperature regulated bias circuit.

BOARD SIZE: 70x100mm - 38x100mm

PACKAGE INCLUDE PRINTED SCHEMATIC AND INFORMATION GUIDE
